Teknik Özellikler
| Range of product | Telemecanique Safety switches XCS |
|---|---|
| Product or component type | Coded magnetic switch |
| [Ue] rated operational voltage | 24 V DC |
| Component name | XCSDMC |
| Enclosure material | Thermoplastic PBT |
| Design | Rectangular, compact |
| Material | Plastic |
| Cable composition | 4 x 0.25 mm² |
| Contacts type and composition | 2 NC |
| Electrical connection | Pre-cabled |
| Size | 51 x 16 x 7 mm |
| Safety level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
| Local signalling | 1 LED |
| Contact operation | Staggered |
| Safety reliability data | B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Contacts material | Rhodium |
| Switching frequency | 150 Hz |
| IP degree of protection | IP66 conforming to IEC 60529, IP67 conforming to IEC 60529 |
| Approach directions | 3 directions |
| Product certifications | CSAUL |
| Insulation resistance | 1000 MOhm |
| Standards | CSA C22.2 No 14IEC 60204-1IEC 60947-5-1ISO 12100ISO 14119UL 508 |
| Cable material | PVC |
| Vibration resistance | 10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6 |
| [Ie] rated operational current | 100 MILLIAMPERE |
| Switching capacity in mA | 5...100 mA |
| Electrical shock protection class | Class II conforming to IEC 61140 |
| Shock resistance | 30 gn for 11 ms conforming to IEC 60068-2-27 |
| Protective treatment | TH |
| Sensitivity to magnetic fields | 0.3 MILLITESLA |
| Unit type of package 1 | PCE |
| Number of units in package 1 | 1 |
| California proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. Fo more information go to www.P65Warnings.ca.gov |
