Teknik Özellikler
| Range of product | Telemecanique Safety switches XCS |
|---|---|
| Product or component type | Preventa RFID safety switch |
| Component name | XCSRC |
| Design | Rectangular, standard |
| Size | Transponder: 50 x 15 x 15 mm, reader: 108.3 x 30 x 15 mm |
| Material | Valox |
| Electrical connection | 1 male connector |
| Connector type | M12 male |
| Type of output stage | Solid-state, PNP |
| Safety outputs | 2 NO |
| Local signalling | Green, orange and red 2 multi-colour LEDs |
| Approach directions | 3 directions-transponder with rotary sensing face |
| [Ue] rated operational voltage | 24 V DC (- 20...10 %)SELV or PELV conforming to IEC 60204-1 |
| Protection type | Short-circuit protection |
| Switching capacity in mA | 400 mA |
| Switching frequency | <= 0.5 Hz |
| Discordance time | 120 ms |
| Response time | 250 ms typical |
| Delay first up | 5 SECOND |
| Tightening torque | < 1.5 N.m |
| Standards | IEC 60947-5-2IEC 60947-5-3ISO 14119 |
| Product certifications | CSA 22-2E2EcolabFCCICRCMTÜV |
| Marking | CEcULusEACFCCICRCMTÜV |
| Safety level | SIL 3 conforming to IEC 61508, SILCL 3 conforming to IEC 62061, PL = e conforming to ISO 13849-1, category 4 conforming to ISO 13849-1 |
| Safety reliability data | PFHD = 5E-10/h conforming to IEC 62061, PFHD = 5E-10/h conforming to ISO 13849-1 |
| Vibration resistance | 10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class III conforming to IEC 61140 |
| IP degree of protection | IP65 conforming to IEC 60529, IP66 conforming to IEC 60529, IP67 conforming to IEC 60529, IP69K conforming to DIN 40050 |
| Unit type of package 1 | PCE |
| Number of units in package 1 | 1 |
| Package 1 height | 2.8 CENTIMETER |
| Package 1 width | 14.7 CENTIMETER |
| Package 1 length | 17.9 CENTIMETER |
| Package 1 weight | 0.104 KILOGRAM |
| Unit type of package 2 | S01 |
| Number of units in package 2 | 12 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 15 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 1.431 KILOGRAM |
| Indivisible sale quantity | 1 |
| California proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
